Features

• Design of pressure intensification up to 1000 bar
• Works on the principle of different bore area ratios
• Suitable for oil, water and various other fluids
• Available in various bore area ratios
• Option: Double-acting booster pumps with higher displacement per stroke, higher capacity hydraulic tanks
• Application: Pressure testing of valves, pressure vessels, fittings, hoses and pipes. Used as power source for clamp heads, hydraulic actuators and expansion of AC condenser coils
